MXP-3 Passive wall mount loudspeaker
Wall Mount Passive Loudspeaker
SPECIFICATIONS
(subject to change) All specifications are within ± 3 dB unless otherwise noted.
Frequency Response (-3 dB) ~120Hz – 20kHz
Nominal Impedance 4Ω
Coverage Angle 98°
Maximum SPL AES75 max linear sound levels: 89 dBZ, 108 dBZpk, 89 dBA
Sensitivity 82 dB SPL 1W/meter
Connector Type 2-pin connector, 0.2 in. (5.08 mm) pitch, Jiekle 2EDG-5.08 V/R
Maximum Input Power 10W
Weight 1.34 lbs (0.61 kg)
Product Dimensions 11.2 x 3.5 x 1.9 in. (283.8 x 90 x 48.5 mm)
Operating Temperature Range -7 to 40°C (19.4 to 104°F)
3.300,00 د.م. 4.200,00 د.م.
OVERVIEW
Passive wall mount loudspeaker for speech and program audio reproduction in meeting rooms
employing enhanced spatial audio. Microflex Conferencing Loudspeakers are designed for
conferencing with clear, intelligible audio.
FEATURES
• Innovative Balanced Mode Radiator (BMR) driver is voiced specifically for speech intelligibility in
conferencing and meeting applications
• Wide dispersion for complete room coverage and consistent sound quality for every listener
• Flat-disc diaphragm provides more natural sound than conventional cone-shaped diaphragms and
a more compact size
• Eliminates the need for a crossover in the critical 1-3 kHz speech frequency range and delivers
sound from a single point source for maximum clarity
• Up to four MXP-3 loudspeakers can be used with the MXN-AMP PoE+ multichannel amplifier
• Compact design with only 2.5-inch depth can be wall mounted horizontally or vertically, or onceiling with included mounting hardware (Note: Shure recommends the use of an additional safety
tether for overhead components.)
• Available in black or white finish, paintable to match room décor
• Seamless connectivity and compatibility with popular collaboration platforms, including Microsoft
Teams and Zoom
